AD230U

AD230U

A Fast, Reliable, and Affordable Scanner
The AD230U is a 40 page-per-minute, duplex scanner that is fast, reliable, and affordable for business where scanning plastic ID cards, business cards, documents or other heavy card stock is necessary. Combining reverse roller and advanced paper feeding technologies, the AD230U balances fast speed with exceptional reliability across a wide variety of scanning situations.

Compact ADF Scanner — 25ppm Duplex Document Scanner

25 ppm
USB 2.0
600 dpi

General Specification
Technology	CMOS-CIS
Light Source	LED
Memory Size	64MB SDRAM
Document Feeding Mode	ADF
Optical Resolution	600 x 600 dpi
Output Resolution	1200 x 1200 dpi
File Formats	BMP PNG GIF JPEG Single-Page PDF Multi-Page PDF Multi-TIFF TIFF RTF TXT OCR XPS DOC XLS PPT DOCX XLSX PPTX HTML
Halftone Patterns	Dither and Error Diffusion
Grayscale Mode	16-bit input, 8-bit output
Color Mode	48-bit input, 24-bit output
Physical Specifications
Dimensions (W × D × H)	299 x 104 x 74 mm
Interface	USB 2.0
Network Connection	NA
Recommended Daily Volume	Up to 3,000 sheets
Software & Compatibility
OS Support	Windows 7 / 8 / 10 / 11 Windows Server 2008R2 / 2012 / 2016 / 2019 / 2022 / 2025 Fedora openSUSE Debian Ubuntu macOS 10.12 ~ 10.15 macOS 11 Big Sur macOS 12 Monterey macOS 13 Ventura macOS 14 Sonoma
Bundled Software	TWAIN Driver ISIS Driver Button Manager PaperPort AVScan
Features
Ultrasonic Paper Jam Detection	Yes
Long Paper Mode	Up to 300 dpi Color Duplex 118 inch (3000 mm)
Card Scan	Embossed card (Thickness 1.25 mm)
Scan Size
ADF Minimum	50 x 50 mm
ADF Maximum	216 x 356 mm (Legal) (8.5 x 14 in.)
ADF Capacity	25 sheets
Paper Weight	ADF: 27 ~ 120 g/m² ; Front: 27 ~ 413 g/m² (7 to 110 lb.)
Scanning Speed
B/W @ 200dpi, A4	Simplex: 25 ppm ; Duplex: 50 ipm
B/W @ 300dpi, A4	Simplex: 25 ppm ; Duplex: 50 ipm
Color @ 200dpi, A4	Simplex: 25 ppm ; Duplex: 50 ipm
Color @ 300dpi, A4	Simplex: 25 ppm ; Duplex: 50 ipm
